Aluminum Strip For Lamp | Aluminum Strip 3004

  • MOQ:2 to 5MT
  • Port:Shanghai,Qing Dao, China
  • Payment Terms:L/C,TT,CAD
  • Delivry Time:15 to 30days
Gallery
  • Details

Our aluminium strip for lamp base materials combines strength and high form-ability with high resistance to softening in vitriting. 3004 aluminum strip temper O is usually used for lamp base materials. Manufactured at modern and well-equipped mills, it can be rolled to very fine tolerances, allowing more caps per tonne of coil and enabling uninterrupted operations of high-speed forming presses.

Specification for aluminum strip for lamp base


Aluminum strip for lamp base
Alloy Temper Specification(mm)
Thickness Width Coil ID
3004 O 0.25-0.40 85-400 75 150
Remark:Special specifications can be produced according to your requirement.


Chemical composition


Alloy Si Fe Cu Mn Mg Cr Ni Zn Ga Ti Al
3004 ≤0.30 ≤0.70 ≤0.25 1.0-1.5 0.8-1.3 ≤0.05 ≤0.05 ≤0.25 - ≤0.05 other


Mechanical property


Alloy Temper Thickness(mm) Width(mm) U.T.S(Mpa) Elongation(%)
3004 O 0.25-0.40 85-400 155-200 ≥13


Tolerance


Thickness Width
±0.005mm ±0.05mm


Packing


Export Standard Package, moisture-proof, strong enough, suit for long distance sea transport. Lampcap stock is placed on wooden pallets/case in an eye-to-wall position.
